QS155 70H 72V 10kW Electric Motor – Hairpin Taper Shaft

$899.95
/
Shipping calculated at checkout.
Only 1 items in stock!
AVAILABLE FOR ORDER

The prices displayed on the website do not include any customs duties or potential import taxes. Additional charges (such as customs duties, taxes, brokerage fees, or any other fees required by the authorities of the destination country) may be requested from the customer by the carrier or the relevant authorities at the time of delivery. These fees, which cannot be reasonably determined in advance, are the sole responsibility of the customer, who is responsible for checking the applicable regulations in their country before placing an order. If you refuse the delivery, a refund will be issued once the package has been received by the sender. Return costs (shipping, taxes, and customs fees) will be deducted from the refunded amount. Please note that if you choose DHL Express, shipments are only picked up on Tuesdays and Thursdays.

QS155‑70H 72V Mid‑Drive Motor – Hairpin Encoder Electric Vehicle Motor with Pulley Output

Can be used for electric dirt bikes, electric motorcycles, electric ATVs, electric go‑karts, electric snowmobiles, utility work vehicles, electric side‑by‑sides, and much more!

Main Features

  • Lightweight and compact compared to hub motors

  • High‑performance advantage thanks to flux weakening

  • High efficiency on climbs and better acceleration

  • Weight (motor only): 31.0 lbs

  • Capable of producing over 25 kW (33.5 hp) peak and 10 kW (13.5 hp) continuous

  • IP67: fully dust‑tight and protected against immersion for 5 minutes

  • High torque output

  • PMSM motor (internal rotor type)

  • Brand: QS MOTOR, SIAECOSYS

  • Magnet height: 70 mm, 4 pole pairs

  • Rated power: 10,000 W

  • Peak power: 25,000 W

  • Rated voltage: 72V

  • Speed: 6000 RPM and 8000 RPM with flux weakening

  • Maximum torque: 92 N·m

  • Cooling method: Air‑cooled

  • Maximum efficiency: 93%

  • Maximum battery current: 400A

  • Thermal sensor: KTY83/122 (default)

  • Operating temperature: ‑30°C to 120°C

  • Encoder sensor: Waterproof connector encoder

  • Phase wire: 25 mm²

  • Voltage: 72V
